298 Analytical Techniques for Atmospheric Measurement
3.0
2.5
2.0
1.5
1.0
0.5
0.0
<200nm particulate organics (µg m
-3
)
140120100806040200
NO
2
(ppb)
Figure 6.11 A regression analysis of NO
x
and the organic mass loading in particles less than 200 nm
aerodynamic diameter measured by an AMS in central Manchester, UK. There is a high degree of
correlation demonstrating that the source of small organic particles is dominated by traffic. These data
were used to calculate an emission rate for primary organic mass from motor vehicles in Manch-
ester of 0.45 tonnes km
−2
year
−1
based on an emission ratio from the National Atmospheric Emissions
Inventory. This compares with the PM
10
emission rate from transport of 1.38 tonnes km
−2
year
−1
(Allan
et al., 2003b).
−40
C. The presence of ice nuclei increases the probability of freezing at temperatures
as high as −5to10
C. However, the number of ice nuclei in the atmosphere is poorly
known and their composition is highly uncertain. As ice nuclei often control the ice
crystal concentration in glaciated clouds, dictating the radiative properties of the cloud
and its precipitation efficiency, the properties of ice nuclei are extremely important. Single
particle mass spectrometric studies are beginning to make a real contribution in this area.
Cziczo et al. (2004) have used the PALMS instrument to investigate ice nuclei both in
the laboratory and in the field and have shown that particles containing organic material
are found preferentially in the droplet phase not the ice phase, indicating that organics
may inhibit ice formation. If that is the case then this has a significant impact on the way
cold clouds will behave towards pollution aerosol.
Aerosol mass spectrometers have now been flown on aircraft to address several very
important questions. A version of the PALMS instrument was fitted to a WB-57F high
altitude research aircraft by Thomson et al. (2000) and is shown in Figure 6.12. The
instrument was mounted into the nose cone to avoid sampling artefacts when entraining
aerosol into the fuselage of a rapidly moving aircraft, with its inlet facing forward of the
aircraft in undisturbed flow. The instrument design had to be capable of withstanding
operation in an environment without ambient pressure control on a platform capable
of reaching altitudes of 19 km and so probe the stratosphere. As shown in Figure 6.13,
Mass Spectrometric Methods for Aerosol Composition Measurements 299
Reflectron
Excimer
laser
Drift tube
Scroll pump
Gate valve
Ion elbow
Ion source
Capillary
Computer
Data system
YAG
Trigger logic
HV supply
carbon fiber table
Main turbo
Radar mount
Inlet
shroud
Figure 6.12 A schematic of the PALMS instrument fitted into the nose cone of the WB-57F aircraft.
(Thomson et al., 2000).
Murphy et al. (1998b) used this instrument to characterise stratospheric aerosol and
showed that in the upper troposphere very often there are more organic containing
particles than those containing sulphate. In the lower stratosphere they showed that most
of the aerosols were made of sulphate–water mixtures. Signatures of meteoritic material
were seen in the lower stratospheric aerosol, which contained over 45 different elements,
demonstrating the complexity of atmospheric aerosol.
Aerosol mass spectrometry has also been used to probe polar stratospheric clouds.
Schreiner et al. (2002) developed a balloon borne mass spectrometer (the ACMS) to
measure the composition of PSCs in the arctic stratosphere. They showed that within
the polar vortex high backscatter ratios, indicating the presence of PSCs, correlated with
high particle water and nitric acid signals, the ratios of which indicated the presence of
drops of ternary solution rather than solid hydrate formation.
At the beginning of the twenty-first century an Aerodyne AMS system was deployed
on an aircraft by Bahreini et al. (2003). The instrument was installed on a Twin Otter
aircraft and made a series of low- to mid-level flights in the troposphere to investigate
the structure of highly polluted layers advected from southeast Asia during the Aerosol
Characterisation Experiment – Asia (ACE-Asia). The data often showed several distinct
and highly polluted layers over the lower 4 km of the atmosphere that were rich in both
sulphate and organic particulate material. The loadings of these components exceeded
10 gm
−3
on some occasions and arose in one broad mode with a central mode vacuum
aerodynamic diameter of around 400–500 nm. These data and those from subsequent
missions are being obtained at sufficiently high time resolution that it is now possible
to obtain radiative closure estimates along the flight track. This level of detail has never
before been possible and opens up routes to help address the current challenges facing
the scientific community to reduce the uncertainty surrounding the impact of aerosols
and clouds on climate.
300 Analytical Techniques for Atmospheric Measurement
460
440
420
400
380
360
340
Potential temperature (K)
6050403020100
(b) Organic peaks (percent of ions)
9 – 25°N
31– 46°N
9
– 25°N
31–
46°N
460
440
420
400
380
360
340
Potential temperature (K)
100806040200
(a) Sulphate Peaks (percent of ions)
Typical tropopause < 25°N
A
B
Typical trop. > 31°N
Figure 6.13 Average profiles showing the percentage of the total ion current measured from a single
particle that can be demonstrated to be sulphate (A) and organic (B). The data are shown in potential
temperature coordinates and show that the organic containing particles are very significant in the upper
troposphere, especially in the tropics, whereas lower stratospheric aerosols are principally composed of
sulphate (Murphy et al., 1998b).
6.7 Summary
The technology of aerosol mass spectrometry has developed extremely quickly over the
last few years and since the mid-1990s has moved from a laboratory demonstration of
feasibility to a wide range of field instruments capable of adding significant and unique
information to large experiments. The instruments are not only being targeted at novel
Mass Spectrometric Methods for Aerosol Composition Measurements 301
problems such as polar stratospheric cloud composition, stratospheric aerosols and ice
nucleation but are also being used extensively in regional and local source apportionment
studies. The quantitative instruments are being used to investigate aerosol processing
and mass transfer rates, in particular the organic fraction. The single particle instru-
ments, often utilising laser ablation/ionisation, offer single particle detection capability
and can observe refractory material. However, though they can quantify size, mass
quantification remains elusive. The advances made at the time of writing applying a
two step desorption-ionisation process using a dual laser approach may help to improve
the situation significantly in this area; however, at present this has not been demon-
strated routinely. In contrast, the thermal ablation systems, such as the AMS have been
developed to quantitatively measure non-refractory material as a function of particle size
but at present these instruments cannot identify mass loadings and mixing state of single
particles, though by combining such instruments with TOF mass spectrometer technology
this should be feasible in the future. These instruments are also capable of utilising other
forms of ionisation methods that are less harsh than electron impact ionisation used
currently. Implementation of techniques such as photo- or chemi-ionisation will lead
to less fragmentation and clearer identification of individual compounds. However, the
thermal ablation methods will largely be restricted to non-refractory material, though in
certain circumstances, surface ionisation can be useful for determining information of
certain ions, in particular the alkali metals.
No instrument so far developed can claim to deliver explicit, complete, quantitative
physiochemical data for all atmospheric aerosol particles and aerosol mass spectrometers
are no exception to this. Because of this, the science of analysing aerosol data is most
effective when the results from many instruments are properly combined within the
context and goals of the study being performed. Bulk sampling and analysis still usually
provides the most authoritative data on overall composition, due to the breadth of
well-established analytical tools available, and the dedicated sizing instruments are still
considered the most reliable for generating number and size data. However, as described
before, the aerosol mass spectrometry methods offer many valuable insights that were
hitherto impossible, so by including their greatly enhanced size and time resolutions,
benefits of in situ analysis and abilities to extensively study individual particles, a vastly
more accurate and detailed picture of aerosol climatology can be obtained in a given
scenario, if the data are used correctly.
Further reading
Seinfeld, J.H. & S.N. Pandis (1998) Atmospheric Chemistry and Physics: From Air Pollution to Climate
Change, John Wiley & Sons, New York, Chichester.
Suess, D.T. and K.A. Prather (1999) Mass spectrometry of aerosols, Chem. Rev., 99 (10), 3007–3035.
McMurry, P.H. (2000) A review of atmospheric aerosol measurements, Atmos. Environ., 34 (12–14),
1959–1999.
Noble, C.A. and K.A. Prather (2000) Real-time single particle mass spectrometry: A historical
review of a quarter century of the chemical analysis of aerosols, Mass Spectrom. Rev., 19 (4),
248–274.
Baron, P.A. & K. Willeke (2001) Aerosol Measurement: Principles, Techniques, and Applications, 2nd
Edition, Wiley-Interscience, New York, Chichester.
302 Analytical Techniques for Atmospheric Measurement
Aerosol Science & Technology, 33 (1–2) (Special Issue), Taylor & Francis, 2000.
Jimenez, J.L. Aerosol Mass Spectrometry Web Page, http://cires.colorado.edu/jimenez/ams.html
References
Adachi, M., Kousaka, Y. & Okuyama, K., (1985) Unipolar and bipolar diffusion charging of ultrafine
aerosol-particles, J. Aerosol Sci., 16 (2), 109–123.
Alfarra, M.R., Coe, H., Allan, J.D., Bower, K.N., Boundries, H., Canagaratna, M.R., Jimenez, J.L.,
Jayne, J.T., Garforth, A., Li, S. & Worsnop, D.R. (2004) Characterization of urban and rural
organic particulate in the Lower Fraser Valley using two aerodyne aerosol mass spectrometers,
Atmos. Environ., 38 (34), 5745–5758.
Allan, J.D., Jimenez, J.L., Williams, P.I., Alfarra, M.R., Bower, K.N., Jayne, J.T., Coe, H. &
Worsnop, D.R. (2003a) Quantitative sampling using an Aerodyne aerosol mass spectrometer – 1.
Techniques of data interpretation and error analysis, J. Geophys. Res.-Atmos., 108 (D3), 4090.
Allan, J.D., Alfarra, M.R., Bower, K.N., Williams, P.I., Gallagher, M.W., Jimenez, J.L.,
McDonald, A.G., Nemitz, E., Canagaratna, M.R., Jayne, J.T., Coe, H. & Worsnop, D.R. (2003b)
Quantitative sampling using an Aerodyne aerosol mass spectrometer – 2. Measurements of fine
particulate chemical composition in two U.K. cities, J. Geophys. Res.-Atmos., 108 (D3), 4091.
Allan, J.D., Coe, H., Bower, K.N., Alfarra, M.R., Delia, A.E., Jimenez, J.L., Middlebrook, A.M.,
Drewnick, F., Onasch, T.B., Canagaratna, M.R., Jayne, J.T. & Worsnop, D.R. (2004a) A gener-
alised method for the extraction of chemically resolved mass spectra from Aerodyne aerosol
mass spectrometer data, J. Aerosol Sci., 35 (7), 909–922.
Allan, J.D., Bower, K.N., Coe, H., Boudries, H., Jayne, J.T., Canagaratna, M.R., Millet, D.B.,
Goldstein, A.H., Quinn, P.K., Weber, R.J. & Worsnop, D.R. (2004b) Submicron aerosol compo-
sition at Trinidad Head, California, during ITCT 2K2: Its relationship with gas phase volatile
organic carbon and assessment of instrument performance, J. Geophys. Res.-Atmos., 109 (D23),
D23S24.
Allen, J. & Gould, R.K. (1981) Mass-spectrometric analyzer for individual aerosol-particles, Rev.
Sci. Instrum., 52 (6), 804–809.
Allen, J.O., Fergenson, D.P., Gard, E.E., Hughes, L.S., Morrical, B.D., Kleeman, M.J., Gross, D.S.,
Galli, M.E., Prather, K.A. & Cass, G.R. (2000) Particle detection efficiencies of aerosol time of
flight mass spectrometers under ambient sampling conditions, Environ. Sci. Technol., 34 (1),
211–217.
Allen, M.D. & Raabe, O.G. (1982) Re-evaluation of Millikan’s oil drop data for the motion of small
particles in air, J. Aerosol Sci., 13 (6), 537–547.
Arnold, R.J. & Reilly, J.P. (1998) Fingerprint matching of E-coli strains with matrix-assisted laser
desorption ionization time-of-flight mass spectrometry of whole cells using a modified corre-
lation approach, Rapid Commun. Mass Spectrom., 12 (10), 630–636.
Bahreini, R., Jimenez, J.L., Wang, J., Flagan, R.C., Seinfeld, J.H., Jayne, J.T. & Worsnop, D.R. (2003)
Aircraft-based aerosol size and composition measurements during ACE-Asia using an aerodyne
aerosol mass spectrometer, J. Geophys. Res. Lett., 108(D23), 8645.
Bhave, P.V., Fergenson, D.P., Prather, K.A. & Cass, G.R. (2001) Source apportionment of fine
particulate matter by clustering single-particle data: Tests of receptor model accuracy, Environ.
Sci. Technol., 35 (10), 2060–2072.
Bhave, P.V., Allen, J.O., Morrical, B.D., Fergenson, D.P., Cass, G.R. & Prather, K.A. (2002) A field-
based approach for determining ATOFMS instrument sensitivities to ammonium and nitrate,
Environ. Sci. Technol., 36 (22), 4868–4879.
Birch, M.E. & Cary, R.A. (1996) Elemental carbon-based method for monitoring occupational
exposures to particulate diesel exhaust, Aerosol Sci. Technol., 25 (3), 221–241.
Mass Spectrometric Methods for Aerosol Composition Measurements 303
Biskos, G., Mastorakos, E. & Collings, N. (2004) Monte-Carlo simulation of unipolar diffusion
charging for spherical and non-spherical particles, J. Aerosol Sci., 35 (6), 707–730.
Bley, W.G. (1988) Quantitative measurements with quadrupole mass spectrometers – Important
specifications for reliable measurements, Vacuum, 38 (2), 103–109.
Boudries, H., Canagaratna, M.R., Jayne, J.T., Alfarra, M.R., Allan, J.D., Coe, H., Pryor, S.C.,
Jimenez, J.L., Brook, J.R., Li, S. & Worsnop, D.R. (2004) Chemical and physical processes
controlling the distribution of aerosols in the Lower Fraser Valley, Canada, during the Pacific
2001 field campaign, Atmos. Environ., 38 (34), 5759–5774.
Brockmann, J.E. & Rader, D.J. (1990) APS Response to nonspherical particles and experimental-
determination of dynamic shape factor, Aerosol Sci. Technol., 13 (2), 162–172.
Buzorius, G., Zelenyuk, A., Brechtel, F. & Imre, D. (2002) Simultaneous determination of individual
ambient particle size, hygroscopicity and composition, Geophys. Res. Lett., 29 (20), 1974.
Cabalo, J., Zelenyuk, A., Baer, T. & Miller, R.E. (2000) Two-color laser induced evaporation
dynamics of liquid aerosols probed by time-of-flight mass spectrometry, Aerosol Sci. Technol.,
33 (1–2), 3–19.
Canagaratna, M.R., Jayne, J.T., Ghertner, D.A., Herndon, S., Shi, Q., Jimenez, J.L., Silva, P.J.,
Williams, P., Lanni, T., Drewnick, F., Demerjian, K.L., Kolb, C.E. & Worsnop, D.R. (2004)
Chase studies of particulate emissions from in-use New York City vehicles, Aerosol Sci. Technol.,
38 (6), 555–573.
Carpenter, G.A., Grossberg, S. & Rosen, D.B. (1991) Art 2-A – An adaptive resonance algorithm
for rapid category learning and recognition, Neural Netw., 4 (4), 493–504.
Carson, P.G., Neubauer, K.R., Johnston, M.V. & Wexler, A.S. (1995) Online chemical-analysis of
aerosols by rapid single-particle mass-spectrometry, J. Aerosol Sci., 26 (4), 535–545.
Carson, P.G., Johnston, M.V. & Wexler, A.S. (1997a) Laser desorption/ionization of ultrafine
aerosol particles, Rapid Commun. Mass Spectrom., 11 (9), 993–996.
Carson, P.G., Johnston, M.V. & Wexler, A.S. (1997b) Real-time monitoring of the surface and total
composition of aerosol particles, Aerosol Sci. Technol., 26 (4), 291–300.
Chen, B.T., Cheng, Y.S. & Yeh, H.C. (1985) Performance of a TSI aerodynamic particle sizer,
Aerosol Sci. Technol., 4 (1), 89–97.
Chen, Y.H., Gonin, M., Fuhrer, K., Dodonov, A., Su, C.S. & Wollnik, H. (1999) Orthogonal electron
impact source for a time-of-flight mass spectrometer with high mass resolving power, Int. J.
Mass Spectrom., 185–187, 221–226.
Chow, J.C. (1995) Measurement methods to determine compliance with ambient air-quality
standards for suspended particles, J. Air Waste Manag. Assoc., 45 (5), 320–382.
Coggiola, M.J., Shi, Z. & Young, S.E. (2000) Airborne deployment of an instrument for the real-time
analysis of single aerosol particles, Aerosol Sci. Technol., 33 (1–2), 20–29.
Colvile, R.N., Hutchinson, E.J., Mindell, J.S. & Warren, R.F. (2001) The transport sector as a source
of air pollution, Atmos. Environ., 35 (9), 1537–1565.
Cunningham, E. (1910) On the velocity of steady fall of spherical particles through fluid medium,
Proceedings of the Royal Society of London. Series A-Containing Papers of a Mathematical and
Physical Character, 83 (563), 357–365.
Cziczo, D.J., DeMott, P.J., Brooks, S.D., Prenni, A.J., Thomson, D.S., Baungardner, D., Wilson, J.C.,
Freideniweis, S.M. & Murphy, D.M. (2004) Observations of organic species and atmospheric
ice formation, Geophys. Res. Lett., 31 (12), 42 116.
Dall’Osto, M., Beddows, D.C.S., Kinnersley, R.P., Harrison, R.M., Donovan, R.J. & Heal, M.R.
(2004) Characterization of individual airborne particles by using aerosol time-of-flight mass
spectrometry at Mace Head, Ireland, J. Geophys. Res.-Atmos., 109 (D21), D21302.
Davidsson, K.O., Engvall, K., Hagström, M., Korsgren, J.G., Lönn, B. & Pettersson, J.B.C. (2002)
A surface ionization instrument for on-line measurements of alkali metal components in
combustion: Instrument description and applications, Energy & Fuels, 16 (6), 1369–1377.
304 Analytical Techniques for Atmospheric Measurement
Davis, W.D. (1973) Surface ionization mass spectroscopy of airborne particulates, J. Vacuum Sci.
Technol., 10 (1), 278.
DeCarlo, P.F., Slowik, J.G., Worsnop, D.R., Davidovits, P. & Jimenez, J.L. (2004) Particle
morphology and density characterization by combined mobility and aerodynamic diameter
measurements. Part 1: Theory, Aerosol Sci. Technol., 38 (12), 1185–1205.
Decesari, S., Facchini, M.C., Fuzzi, S. & Tagliavini, E. (2000) Characterization of water-soluble
organic compounds in atmospheric aerosol: A new approach, J. Geophys. Res.-Atmos., 105 (D1),
1481–1489.
Dockery, D.W., Pope, C.A., Xu, X.P., Spengler, J.D., Ware, J.H., Fay, M.E., Ferris, B.G. &
Speizer, F.E. (1993) An association between air-pollution and mortality in 6 United States cities,
N. Engl. J. Med., 329 (24), 1753–1759.
Drewnick, F., Schwab, J.J., Hogrefe, O., Peters, S., Husain, L., Diamond, D., Weber, R. &
Demerjian, K.L. (2003) Intercomparison and evaluation of four semi-continuous PM2.5 sulfate
instruments, Atmos. Environ., 37 (24), 3335–3350.
Drewnick, F., Hings, S.S., DeCarlo, P., Jayne, J.T., Gonin, M., Fuhrer, K., Weimer, S., Jimenez, J.L.,
Demerjian, K.L., Borrmann, S. and Worsnop, D.R. (2005) A new time-of-flight aerosol
mass spectrometer (TOF-AMS) instrument description and first field deployment, Aerosol Sci.
Technol., 39 (7), 637–658.
Dye, A.L., Rhead, M.M. & Trier, C.J. (2000) The quantitative morphology of roadside and
background urban aerosol in Plymouth, UK, Atmos. Environ., 34 (19), 3139–3148.
Fergenson, D.P., Song, X.H., Ramadan, Z., Allen, J.O., Hughes, L.S., Cass, G.R., Hopke, P.K. &
Prather, K.A. (2001) Quantification of ATOFMS data by multivariate methods, Anal. Chem.,73
(15), 3535–3541.
Flagan, R. (2004) Opposed migration aerosol classifier (OMAC), Aerosol Sci. Technol., 38 (9),
890–899.
Flagan, R.C. (1998) History of electrical aerosol measurements, Aerosol Sci. Technol., 28 (4), 301–
380.
Fuchs, N. (1963) On the stationary charge distribution on aerosol particles in a bipolar ionic
atmosphere, Geofisica pura e applicata, 56, 185–193.
Fuchs, N.A. (1964) Steady rectilinear motion of aerosol particles, in The Mechanics of Aerosols:
Revised and Enlarged Edition, pp. 21–69, Pergamon Press, Oxford; London; Edinburgh; New
York; Paris; Frankfurt.
Gard, E., Mayer, J.E., Morrical, B.D., Dienes, T., Fergenson, D.P. & Prather, K.A. (1997) Real-
time analysis of individual atmospheric aerosol particles: Design and performance of a portable
ATOFMS, Anal. Chem., 69 (20), 4083–4091.
Ge, Z.Z., Wexler, A.S. & Johnston, M.V. (1998) Laser desorption/ionization of single ultrafine
multicomponent aerosols, Environ. Sci. Technol., 32 (20), 3218–3223.
Gieray, R.A., Reilly, P.T.A., Yang, M., Whitten, W.B. & Ramsey, J.M. (1998) Tandem mass
spectrometry of uranium and uranium oxides in airborne particulates, Anal. Chem., 70 (1),
117–120.
Grix, R., Grüner, U., Li, G., Stroh, H. & Wollnik, H. (1989) An electron-impact storage ion-source
for time-of-flight mass spectrometers, Int. J. Mass Spectrom. Ion Processes, 93 (3), 323–330.
Gross, D.S., Galli, M.E., Silva, P.J. & Prather, K.A. (2000) Relative sensitivity factors for alkali metal
and ammonium cations in single particle aerosol time-of-flight mass spectra, Anal. Chem.,72
(2), 416–422.
Guazzotti, S.A., Suess, D.T., Coffee, K.R., Quinn, P.K., Bates, T.S., Wisthalu, A., Hansel, A.,
Ball, W.P., Dickerson, R.R., Neususs, C., Crutzen, P.J. & Prathee, K.A. (2003) Characterization
of carbonaceons aerosols outflow from India and Arabia: Biomass/biofuel burning and fossil
fuel combustion, J. Geophys. Res. Atmos., 108 (D15), 4485.
Harrison, R.M. & Yin, J.X. (2000) Particulate matter in the atmosphere: Which particle properties
are important for its effects on health?, Sci. Total Environ., 249 (1–3), 85–101.
Mass Spectrometric Methods for Aerosol Composition Measurements 305
Hearn, J.D. & Smith, G.D. (2004) A chemical ionization mass spectrometry method for the online
analysis of organic aerosols, Anal. Chem., 76 (10), 2820–2826.
Hinz, K.P., Kaufmann, R. & Spengler, B. (1994) Laser-induced mass analysis of single particles in
the airborne state, Anal. Chem., 66 (13), 2071–2076.
Hinz, K.P., Kaufmann, R. & Spengler, B. (1996) Simultaneous detection of positive and negative
ions from single airborne particles by real-time laser mass spectrometry, Aerosol Sci. Technol.,
24 (4), 233–242.
Hinz, K.P., Greweling, M., Drews, F. & Spengler, B. (1999) Data processing in on-line laser mass
spectrometry of inorganic, organic, or biological airborne particles, J. Am. Soc. Mass Spectrom.,
10 (7), 648–660.
Hoffmann, T., Bandur, R., Hoffmann, S. & Warscheid, B. (2002) On-line characterization of
gaseous and particulate organic analytes using atmospheric pressure chemical ionization mass
spectrometry, Spectrochimica Acta Part B-Atomic Spectroscopy, 57 (10), 1635–1647.
Hunt, A.L. & Petrucci, G.A. (2002) Analysis of ultrafine and organic particles by aerosol mass
spectrometry, Trac-Trends Anal. Chem., 21 (2), 74–81.
Jacobson, M.C., Hansson, H.C., Noone, K.J. & Charlson, R.J. (2000) Organic atmospheric aerosols:
Review and state of the science, Rev. Geophys., 38 (2), 267–294.
Jäglid, U., Olsson, J.G. & Pettersson, J.B.C. (1996) Detection of sodium and potassium salt particles
using surface ionization at atmospheric pressure, J. Aerosol Sci., 27 (6), 967–977.
Jayne, J.T., Leard, D.C., Zhang, X.F., Davidovits, P., Smith, K.A., Kolb, C.E. & Worsnop, D.R.
(2000) Development of an aerosol mass spectrometer for size and composition analysis of
submicron particles, Aerosol Sci. Technol., 33 (1–2), 49–70.
Jimenez, J.L., Jayne, J.T., Shi, Q., Kolb, C.E., Worsnop, D.R., Yourshaw, I., Seinfeld, J.H.,
Flagan, R.C., Zhang, X., Smith, K.A., Morris, J.W. & Davidovits, P. (2003a) Ambient aerosol
sampling using the aerodyne aerosol mass spectrometer, J. Geophys. Res.-Atmos., 108 (D7), 8425.
Jimenez, J.L., Bahreini, R., Cocker, D.R., Zhuang, H., Varutbangkul, V., Flagan, R.C., Seinfeld, J.H.,
O’Dowd, C.D. & Hoffmann, T. (2003b) New particle formation from photooxidation of
diiodomethane (CH2I2), J. Geophys. Res.-Atmos., 108 (D10), 4318.
Jimenez, J.L., Bahreini, R., Cocker, D.R., Zhuang, H., Varutbangkul, V., Flagan, R.C., Seinfeld, J.H.,
O’Dowd, C.D. & Hoffmann, T. (2003c) Correction to “New particle formation from photoox-
idation of diiodomethane (CH2I2)”, J. Geophys. Res.-Atmos., 108 (D23), 4733.
Johnston, M.V. (2000) Sampling and analysis of individual particles by aerosol mass spectrometry,
J. Mass Spectrom., 35 (5), 585–595.
Kane, D.B. & Johnston, M.V. (2000) Size and composition biases on the detection of individual
ultrafine particles by aerosol mass spectrometry, Environ. Sci. Technol., 34 (23), 4887–4893.
Kane, D.B., Oktem, B. & Johnston, M.V. (2001) Nanoparticle detection by aerosol mass
spectrometry, Aerosol Sci. Technol., 34 (6), 520–527.
Kelly, W.P. & McMurry, P.H. (1992) Measurement of particle density by inertial classification
of differential mobility analyzer generated monodisperse aerosols, Aerosol Sci. Technol., 17 (3),
199–212.
Khlystov, A., Wyers, G.P. & Slanina, J. (1995) The steam-jet aerosol collector, Atmos. Environ.,29
(17), 2229–2234.
Kinsel, G.R. & Johnston, M.V. (1989) Post source pulse focusing – A simple method to achieve
improved resolution in a time-of-flight mass-spectrometer, Int. J. Mass Spectrom. Ion Processes,
91 (2), 157–176.
Knutson, E.O. & Whitby, K.T. (1975) Aerosol classifcation by electric mobility: Apparatus, theory,
and application, J. Aerosol Sci., 6 (6), 443–451.
Kulmala, M. (2003) How particles nucleate and grow, Science, 302 (5647), 1000–1001.
Kulmala, M., Vehkamaki, H., Petajda, T., Dal Maso, M., Lauri, A., Kerminen, V.M., Birmili, W. &
McMurry, P.H. (2004) Formation and growth rates of ultrafine atmospheric particles: A review
of observations, J. Aerosol Sci., 35 (2), 143–176.
306 Analytical Techniques for Atmospheric Measurement
LaFranchi, B.W. & Petrucci, G.A. (2004) Photoelectron resonance capture ionization (PERCI):
A novel technique for the soft-ionization of organic compounds, J. Am. Soc. Mass Spectrom.,15
(3), 424–430.
LaFranchi, B.W., Zahardis, J. & Petrucci, G.A. (2004) Photoelectron resonance capture ionization
mass spectrometry: A soft ionization source for mass spectrometry of particle-phase organic
compounds, Rapid Commun. Mass Spectrom., 18 (21), 2517–2521.
Lake, D.A., Tolocka, M.P., Johnston, M.V. & Wexler, A.S. (2003) Mass spectrometry of individual
particles between 50 and 750 nm in diameter at the Baltimore supersite, Environ. Sci. Technol.,
37 (15), 3268–3274.
Lazar, A., Reilly, P.T.A., Whitten, W.B. & Ramsey, J.M. (1999) Real-time surface analysis of
individual airborne environmental particles, Environ. Sci. Technol., 33 (22), 3993–4001.
Lazar, A.C., Reilly, P.T.A., Whitten, W.B. & Ramsey, J.M. (2000) Laser desorption/in situ chemical
ionization aerosol mass spectrometry for monitoring tributyl phosphate on the surface of
environmental particles, Anal. Chem., 72 (9), 2142–2147.
Li, J., Anderson, J.R. & Buseck, P.R. (2003) TEM study of aerosol particles from clean and polluted
marine boundary layers over the North Atlantic, J. Geophys. Res.-Atmos., 108 (D6), 4189.
Liu, B.Y.H. & Pui, D.Y.H. (1974) Electrical neutralization of aerosols J. Aerosol Sci., 5 (5), 465–472.
Liu, P., Ziemann, P.J., Kittelson, D.B. & McMurry, P.H. (1995a) Generating particle beams of
controlled dimensions and divergence: I. Theory of particle motion in aerodynamic lenses and
nozzle expansions, Aerosol Sci. Technol., 22 (3), 293–313.
Liu, P., Ziemann, P.J., Kittelson, D.B. & McMurry, P.H. (1995b) Generating particle beams of
controlled dimensions and divergence: II. Experimental evaluation of particle motion in aerody-
namic lenses and nozzle expansions, Aerosol Sci. Technol., 22 (3), 314–324.
Mader, B.T., Schauer, J.J., Seinfeld, J.H., Flagan, R.C., Yu, J.Z., Yang, H., Lim, H.J., Turpin, B.J.,
Deminter, J.T., Heidemann, G., Bae, M.S., Quinn, P., Bate, T., Eatough, D.J., Huebert, B.J.,
Bertram, T. & Howell, S. (2003) Sampling methods used for the collection of particle-phase
organic and elemental carbon during ACE-Asia, Atmos. Environ., 37 (11), 1435–1449.
Mahadevan, R., Lee, D., Sakurai, H. & Zachariah, M.R. (2002) Measurement of condensed-phase
reaction kinetics in the aerosol phase using single particle mass spectrometry, J. Phys. Chem. A,
106 (46), 11 083–11 092.
Mallina, R.V., Wexler, A.S., Rhoads, K.P. & Johnston, M.V. (2000) High speed particle beam
generation: A dynamic focusing mechanism for selecting ultrafine particles, Aerosol Sci. Technol.,
33 (1–2), 87–104.
Mansoori, B.A., Johnston, M.V. & Wexler, A.S. (1996) Matrix-assisted laser desorption/ionization
of size- and composition selected aerosol particles, Anal. Chem., 68 (20), 3595–3601.
Mayer, H. (1999) Air pollution in cities, Atmos. Environ., 33 (24–25), 4029–4037.
McFiggans, G.B., Coe, H., Burgess, R., Allan, J.D., Cubison, M., Alfarra, M.R., Saunders, R., Saiz-
Lopez, A., Plane, J.M.C., Wevill, D., Carpenter, L., Rickard, A.R. & Monks, P.S. (2004) Direct
evidence for coastal iodine particles from Laminaria macroalgae – Linkage to emissions of
molecular iodine, Atmos. Chem. Phys., 4 (3), 701–713.
McKeown, P.J., Johnston, M.V. & Murphy, D.M. (1991) Online single-particle analysis by laser
desorption mass-spectrometry, Anal. Chem., 63 (18), 2069–2073.
McLafferty, F.W. & Turecek, F. (1993) Interpretation of Mass Spectra, 4th edition, University Science
Books, Mill Valley, CA.
McMurry, P.H., Litchy, M., Huang, P.F., Cai, X.P., Turpin, B.J., Dick, W.D. & Hanson, A. (1996)
Elemental composition and morphology of individual particles separated by size and hygro-
scopicity with the TDMA, Atmos. Environ., 30 (1), 101–108.
McMurry, P.H., Wang, X., Park, K. & Ehara, K. (2002) The relationship between mass and mobility
for atmospheric particles: A new technique for measuring particle density, Aerosol Sci. Technol.,
36 (2), 227–238.
Mass Spectrometric Methods for Aerosol Composition Measurements 307
Middlebrook, A.M., Murphy, D.M., Lee, S.H., Thomson, D.S., Prather, K.A., Wenzel, R.J.,
Liu, D.Y., Phares, D.J., Rhoads, K.P., Wexler, A.S., Johnston, M.V., Jimenez, J.L., Jayne,
J.T., Worsnop, D.R., Yourshaw, I., Seinfeld, J.H. & Flagan, R.C. (2003) A comparison of
particle mass spectrometers during the 1999 Atlanta Supersite Project, J. Geophys. Res.-Atmos.,
108 (D7), 8424.
Mie, G. (1908) Beitraege zur Optik trueber Medien, speziell kolloidaler Metalosungen, Annales de
Physik, 25, 377–445.
Morrical, B.D., Fergenson, D.P. & Prather, K.A. (1998) Coupling two-step laser
desorption/ionization with aerosol time-of-flight mass spectrometry for the analysis of individual
organic particles, J. Am. Soc. Mass Spectrom., 9 (10), 1068–1073.
Murphy, D.M. & Thomson, D.S. (1995) Laser ionization mass-spectroscopy of single aerosol-
particles, Aerosol Sci. Technol., 22 (3), 237–249.
Murphy, D.M., Thomson, D.S. & Middlebrook, A.M. (1997) Bromine, iodine, and chlorine in
single aerosol particles at Cape Grim, Geophys. Res. Lett., 24 (24), 3197–3200.
Murphy, D.M., Thomson, D.S., Middlebrook, A.M. & Schein, M.E. (1998a) In situ single-particle
characterization at Cape Grim, J. Geophys. Res. Lett., 103 (D13), 16 485–16 491.
Murphy, D.M., Thomson, D.S. & Mahoney, T.M.J. (1998b) In situ measurements of organics,
meteoritic material, mercury, and other elements in aerosols at 5 to 19 kilometers, Science, 282
(5394), 1664–1669.
Murphy, D.M., Middlebrook, A.M., & Warshawsky, M. (2003) Cluster analysis of data from the
Particle Analysis by Laser Mass Spectrometry (PALMS) instrument, Aerosol Sci. Technol., 37 (4),
382–391.
Murphy, D.M., Cziczo, D.J., Hudson, P.K., Schein, M.E. & Thomson, D.S. (2004) Particle density
inferred from simultaneous optical and aerodynamic diameters sorted by composition, J. Aerosol
Sci., 35 (1), 135–139.
Myers, R.L. & Fite, W.L. (1975) Electrical detection of airborne particulates using surface ionization
techniques, Environ. Sci. Technol., 9 (4), 334–336.
Neubauer, K.R., Johnston, M.V. & Wexler, A.S. (1998) Humidity effects on the mass spectra of
single aerosol particles, Atmos. Environ., 32 (14–15), 2521–2529.
Nier, A.O. & Schlutter, D.J. (1985) High-performance double-focusing mass-spectrometer, Rev.
Sci. Instrum., 56 (2), 214–219.
NIST Mass Spec Data Center (Director S.E. Stein) (2003) Mass Spectra, in NIST Chemistry WebBook,
NIST Standard Reference Database Number 69, P.J. Linstrom & W.G. Mallard (eds), National
Institute of Standards and Technology, Gaithersburg, MD.
Noble, C. & Prather, K. (1998) Air pollution: The role of particles, Physics World, 11 (1), 39–43.
Öktem, B., Tolocka, M.P. & Johnston, M.V. (2004) On-line analysis of organic components in
fine and ultrafine particles by photoionization aerosol mass spectrometry, Anal. Chem., 76 (2),
253–261.
Orsini, D.A., Ma, Y.L., Sullivan, A., Sierau, B., Baumann, K. & Weber, R.J. (2003) Refinements to
the particle-into-liquid sampler (PILS) for ground and airborne measurements of water soluble
aerosol composition, Atmos. Environ., 37 (9–10), 1243–1259.
Parker, E.P., Trahan, M.W., Wagner, J.S., Rosenthal, S.E., Whitten, W.B., Gieray, R.A.,
Reilly, P.T.A., Lazar, A.C. & Ramsey, J.M. (2000) Detection and classification of individual
airborne microparticles using laser ablation mass spectroscopy and multivariate analysis, Field
Anal. Chem. Technol., 4 (1), 31–42.
Patashnick, H. & Rupprecht, E.G. (1991) Continuous PM-10 measurements using the tapered
element oscillating microbalance, J. Air Waste Manag. Assoc., 41 (8), 1079–1083.
Penner, J.E., Andreae, M., Annegarn, H., Barrie, L., Feichter, J., Hegg, D., Jayaraman, A., Leaitch, R.,
Murphy, D., Nganga, J. & Pitari, G. (2001) Aerosols, their direct and indirect effects, in Climate
Change 2001: The Scientific Basis. Contribution of Working Group I to the Third Assessment Report
