166 Computational Fluid Dynamics and Heat Transfer

Velocity residual

−6

−5

−4

−2

−3

−1

Velocity residual

−6

−5

−4

−2

−3

−1

Iterations

AC-CBS

SI-CBS

AC-CBS

SI-CBS

(a) (b)

Figure 4.36. ConvergencehistoriesforSIandAC.(a)Ra=7×10

andDa=10

−4

;

(b) Ra=10

and Da=10

−3

Table 4.2. CPU time (s) for natural convection in a porous cavity heated from the

bottom at different Rayleigh and Darcy numbers

Ra 10

7×10

Da 10

−3

−4

−3

−4

AC-CBS 180 930 290 700

SI-CBS 63,270 48,230 53,400 47,560

the right hand side of the momentum conservation equation in gravity direction

that must be evaluated at each time step.This term can be calculated only after the

resolution ofthe energy equation (step4 ofthe CBS algorithm),due to thef act that

the nodal temperature values are unknown.This coupled system becomes stiff and

causes a restriction on the global time step value used in the SI procedure and thus

thesolution tothesimultaneous equationsatthe secondstepofthealgorithm needs

more time.

Moreover, the SI scheme experiences difﬁculties in reaching the steady state

when very reﬁned meshes are used (Massarotti et al. [47]). On the other hand, the

AC-CBS scheme does not show any problem in reaching the convergence when

natural convection ﬂow occurs.Thereason forthis is therobust localtime stepping

procedure used by theAC-CBS scheme.

The last example is the developing mixed convection in a region partially ﬁlled

with a ﬂuid-saturated porous medium, conﬁned between two vertical hot walls.

In particular, because of the geometrical symmetry, half domain has been studied.

Figure4.37showsthecomputationaldomainandtheboundaryconditionsemployed

andthe detailsofthe computationalgridnear theentrance.Themeshemployedhas

Sunden CH004.tex 10/9/2010 15: 9 Page 167

Applications of ﬁnite element method to heat convection problems 167

u = v =0

(a) (b)

T =1

v = 1, T =0

u = v =0

T =1

Figure 4.37. Mixed convection in a vertical channel partially ﬁlled with a

porousmedium. (a)Computationaldomain andboundaryconditions;

(b)detailofthestructuredcomputationalgridneartheentrance(8,591

nodes and 16,800 elements).

v/v

y =3

y =32

y = 0.5

Chang [48]

AC-CBS

1.5

0.5

Figure 4.38. Mixed convection in a vertical parallel plate channel partially ﬁlled

witha porousmedium. Non-dimensionalverticalvelocityat different

heights of the channel and at Da=10

−5

8,591 nodes and 16,800 elements and is reﬁned near the wall, near the inlet region

and at the interface.

Figure4.38showsthedimensionlessverticalvelocityproﬁleatdifferentheights

ofthechannel(y)foraDarcynumberequalto10

−5

,obtainedbyusingtheAC-CBS

scheme.The present results are compared with the numerical results of Chang and

Sunden CH004.tex 10/9/2010 15: 9 Page 168

168 Computational Fluid Dynamics and Heat Transfer

Chang[48].The parametersused forthe presentinvestigation areRa=0.72×10

Pr=0.72, Re=50, λ =2.8 in the porous region and λ =1 in the free ﬂuid region,

ε =0.8. When y is small, there is a large velocity difference at the interface of the

compositesystem(Figure4.38).Wheny increases,theﬂowdischargeintheporous

layer decreases, and the peak of the ﬂuid velocity proﬁle moves to the central axis

of the vertical parallel-plate channel.
