CHAPTER 5

INSTITUTIONALIZING OPERATIONAL RESILIENCE

MANAGEMENT PROCESSES

5.1 Overview

This chapter describes the process institutionalization aspects of CERT-RMM. It

describes the “continuous representation” of CERT-RMM, the resultant capability

levels, and the associated generic goals and generic practices of CERT-RMM,

which have been sourced intact from CMMI. These model components directly

address process institutionalization.

The capability dimension of CERT-RMM sets it apart from other models in the

operational resilience space because this dimension determines the degree to

which

• a process (or a practice) has been ingrained in the way work is defined, executed,

and managed

• there is commitment and consistency to performing the process

Higher degrees of process institutionalization often equate to more stable

processes that produce consistent results over time. Highly institutionalized

operational resilience management processes should help the organization to

improve service resilience not only because the process is stable but also because

institutionalized processes are more likely to be retained during times of stress.

Because the operational resilience of an organization is fundamentally tied to

how well it performs during times of stress, the capability dimension of CERT-

RMM is foundationally important to any organization that wants to improve its

operational resilience.

68 PART TWO PROCESS INSTITUTIONALIZATION AND IMPROVEMENT

5.2 Understanding Capability Levels

CERT-RMM is not a prescriptive model; that is, there is no guidance provided to

adopt the model in any sequential or prescriptive path. Process improvement is

unique to each organization; thus, CERT-RMM provides the basic structure to

allow organizations to chart their own specific improvement path using the

model as the basis.

The ability to incrementally improve processes in an individual process area

(or a group of process areas) is embedded in the model’s continuous representation.

The improvement path in a continuous representation is defined by capability lev-

els. Levels characterize improvement from an ill-defined state to a state where

processes are characterized and used consistently across organizational units. This

concept is an important enabler of the principle of convergence, particularly in

large, distributed organizations.

To re ac h a p a rt i cu la r l e ve l, a n o rg an iz at io n m us t s at is fy a ll o f t he a pp ro pr i at e

goals of the process area (or a set of process areas), as well as the generic goals

that apply to the specific capability level. The structure of the continuous repre-

sentation for CERT-RMM is provided in Figure 5.1.

Because there is no staged representation in CERT-RMM, technically the con-

cept of organizational maturity for managing operational resilience processes

doesn’t exist. However, it could be argued that an organization that reaches

higher capability levels in each process area is exhibiting a higher degree of orga-

nizational maturity.

The capability dimension of CERT-RMM is also used for process improvement

appraisal activities. Appraisal activities are described in Section 6.4.

CERT-RMM currently defines four capability levels, designated by the num-

bers 0 through 3, as shown in Table 5.1.

A capability level for a process area is achieved when all of the generic goals are

satisfied up to that level. By design, capability level 2 is defined by generic goal 2

and capability level 3 is defined by generic goal 3. Thus, the generic goals and

practices at each level define the meaning of the capability levels. Because capabil-

ity is cumulative, reaching capability level 3 means that the organization is also

performing the goals and practices at capability levels 1 and 2. (See Section 5.4 for

more information about generic goals and practices.)

1. In CERT-RMM, there is no staged representation as in CMMI models. The staged representation uses maturity

levels, which define levels of organizational maturity. In addition, the levels in a staged representation correlate to a

collection of process areas that are prescribed or “staged” at each level. This concept does not exist in CERT-RMM

because all improvement activities are undertaken in an individual process area or a collection of process areas that

are chosen by the organization to satisfy its unique process improvement objectives.

Chapter 5 Institutionalizing Operational Resilience Management Processes 69

5.3 Connecting Capability Levels to Process Institutionalization

Capability levels describe the degree to which a process has been institutional-

ized. Likewise, the degree to which a process is institutionalized is defined by the

generic goals and practices. Table 5.2 links capability levels to the progression of

processes and generic goals.

The progression of capability levels and the degree of process institutionalization

are characterized in the following descriptions.

FIGURE 5.1

Structure of the CERT-RMM Continuous Representation

TA BL E 5 .1 Ca pa b il i ty Le ve ls i n CE RT- R M M

Capability Level Number Capability Level

0 Incomplete

1 Performed

2 Managed

3 Defined

Purpose

Statement

Introductory

Notes

Related Process

Areas

Generic

Goals

Specific

Practices

Generic

Practices

Capability Levels

Typical Work

Products

Subpractices

Subpractice

Elaborations

Subpractices

Specific

Goals

Process Area

(PA)

70 PART TWO PROCESS INSTITUTIONALIZATION AND IMPROVEMENT

5.3.1 Capability Level 0: Incomplete

An incomplete process is a process that either is not performed or is partially per-

formed. One or more of the specific goals of the process area are not satisfied. No

generic goals exist for this level since there is no reason to institutionalize a par-

tially performed process [CMMI Product Team 2006].

5.3.2 Capability Level 1: Performed

Capability level 1 characterizes a performed process. A performed process is a

process that satisfies all of the specific goals of the process area.

It supports and

enables the work needed to perform operational resilience practices as defined by

the specific goals.

Although achieving capability level 1 results in important improvements,

those improvements can be lost over time if they are not institutionalized. The

application of institutionalization through the generic goals at levels 2 and 3

helps to ensure that improvements are maintained [CMMI Product Team 2006].

When organizations perform a compliance review against a code of practice,

they are in essence evaluating whether a process is performed. However, because

operational resilience management processes are critically important during

times of stress, simply verifying that a process is performed does not provide any

indication or predictability about how the organization will perform in the

future. In CERT-RMM, two additional and important levels of capability can be

evaluated—managed and defined—which provide a better indicator of an organi-

zation’s ability to predict performance.

5.3.3 Capability Level 2: Managed

A capability level 2 process is characterized as a managed process. Because capa-

bility levels are cumulative, a managed process is a performed process that has the

2. In CERT-RMM, as in CMMI models, all of the specific goals of a process area must be satisfied to state that the

process is being performed or that the organization is performing the process at capability level 1.

TA BL E 5 . 2 C ap a b il i t y Le v el s R e la t e d t o G o a ls a nd Pro ce ss Pr og re ssi o n

Capability Level Generic Goal Capability

Number Number Level Progression of Processes

0 N/A Incomplete No process or partially performed process

1 GG1 Performed Performed process

2 GG2 Managed Managed process

3 GG3 Defined Defined process

Chapter 5 Institutionalizing Operational Resilience Management Processes 71

basic infrastructure in place to support the process. At capability level 2, the

process

• is planned and executed in accordance with policy

• employs skilled people who have adequate resources to produce controlled

outputs

• involves relevant stakeholders

• is monitored, controlled, and reviewed

• is evaluated for adherence to the organization’s process description

A critical distinction between a performed and a managed process is that a

managed process is planned and the performance of the process is managed

against the plan. Corrective actions are taken when the actual results and per-

formance deviate significantly from the plan. A managed process achieves the

objectives of the plan and is institutionalized for consistent performance [CMMI

Product Team 2006].

The process discipline reflected by capability level 2 helps to ensure that

existing practices are retained during times of stress [CMMI Product Team 2006].

From an operational resilience management perspective, it is at capability level 2

where the organization can begin to answer some vital questions about its viabil-

ity in a complex, risk-evolving environment, such as these:

• Are we able to achieve consistent results from our processes today and tomorrow,

and are we committed to doing so?

• Can we repeat our current successes consistently over time?

• Can we achieve the same results from our processes during times of stress and

when we don’t have access to our best employees and other resources?

• Can we obtain consistent results from our processes across organizational units

and lines of business?

Organizations operating at capability level 2 should begin to know with some

degree of certainty that they can achieve and sustain operational resilience goals

regardless of changes in risk environments or when faced with new and emerging

threats. Thus, instead of shifting its planning and practices for security and busi-

ness continuity to address the next new and sensational threat, the organization

stays on course and defines and refines its processes to address whatever risk

comes its way. This indicates that the organization has invested in and nurtured

its capabilities for sustaining these practices through sponsorship, ability and

commitment, institutionalization, and measurement.

72 PART TWO PROCESS INSTITUTIONALIZATION AND IMPROVEMENT

5.3.4 Capability Level 3: Defined

A capability level 3 process is characterized as a defined process. A defined

process is a managed process (capability level 2) that is tailored from the organi-

zation’s set of standard processes according to the organization’s tailoring guide-

lines. The process also contributes work products, measures, and other process

improvement information as organizational process assets for use by all organiza-

tional units [CMMI Product Team 2006].

What does this ultimately mean to the organization? One of the principal

challenges for effective operational resilience management is the ability to get all

parts of the organization to coalesce around common goals and objectives. When

different parts of the organization operate with different goals, assumptions, and

practices, it is difficult if not impossible to ensure that the organization’s collec-

tive goals and objectives can be reached. This is particularly true with crosscut-

ting concerns such as operational risk management. If the organization’s risk

assumptions are not reflected consistently in security, continuity, and IT opera-

tions activities, the organization’s risk management process will be less than

effective and perhaps significantly detrimental to overall operational resilience.

At capability level 3, alignment begins to occur because the standards, process

descriptions, and procedures used for operational resilience management at the

organizational unit level are tailored from the organization’s standard set of oper-

ational resilience management processes. At capability level 2, each organiza-

tional unit may be improving the degree to which processes are institutionalized

for that unit, but the organization is not necessarily reaping improvement bene-

fits as a whole. At capability level 3, this begins to occur because there is more

consistency across units, and improvements made by each organizational unit

can be accessed and used by the organization through an organization-level

improvement infrastructure.

Another critical distinction at capability level 3 is that processes are typically

described more rigorously than at capability level 2. A defined process clearly

states the purpose, inputs, entry criteria, activities, roles, measures, verification

steps, outputs, and exit criteria. At capability level 3, processes are managed more

proactively using an understanding of the interrelationships of the process activi-

ties and details [CMMI Product Team 2006].

5.3.5 Other Capability Levels

If your organization uses the CMMI models, you are likely to be familiar with two

other capability levels—capability level 4 (quantitatively managed) and capability

level 5 (optimized). Both levels address the use of statistical and other quantitative

techniques to control and improve processes. Beginning at capability level 4,

process quality and performance are understood in statistical terms, and at

Chapter 5 Institutionalizing Operational Resilience Management Processes 73

capability level 5, common causes of process variation are understood and used

for improving the range of process performance.

In CERT-RMM, it is unclear at this point whether these capability levels exist

for operational resilience management or, more specifically, whether they have

meaning. In other words, should an organization strive for some level of quanti-

tatively managed operational resilience processes, and if so, what benefits would

this bring to the organization? Thus, these additional levels are not defined in the

model.

5.4 CERT-RMM Generic Goals and Practices

Generic goals and practices are common to all process areas. They are the

roadmap for helping the organization raise its performance of each process area

to the next capability level. The degree of process institutionalization is embod-

ied in the generic goals and practices and expressed in the names of the generic

goals, except for goal 1, “Achieve Specific Goals,” which refers to the achieve-

ment of all of the specific goals and the performance of all of the specific prac-

tices of a process area.

The generic goals and practices used in CERT-RMM have been sourced from

CMMI models. Thus, if you are a current user of CMMI models, you will be able

to use the same process institutionalization features of CMMI in your CERT-

RMM process improvement effort. However, there are a few differences, mostly in

wording:

• Generic practice 2.1 in CMMI models is “Establish an Organizational Policy,”

while in CERT-RMM, the corresponding practice is “Establish Process Gover-

nance.” In CERT-RMM, policy is an artifact of effective governance, which is

required for all processes to reach capability level 2.

• In CMMI, generic practice 2.3, “Provide Resources,” is similar between the

models, but CERT-RMM expands the definition of “resources” to include

financial resources.

• Generic practice 2.6 in CMMI is “Manage Configurations,” but in CERT-RMM,

it is retitled as “Manage Work Product Configurations” to avoid confusion with

traditional configuration management activities as defined in IT operations.

• CERT-RMM includes subpractices in its articulation of generic goals and practices,

which were eliminated in current versions of CMMI models.

Remember, only the generic goals for capability levels 1, 2, and 3 from CMMI

are included in CERT-RMM. The CERT-RMM Generic Goals and Practices are

included in Appendix A.

74 PART TWO PROCESS INSTITUTIONALIZATION AND IMPROVEMENT

5.4.1 CERT-RMM Elaborated Generic Goals and Practices

Since generic goals and practices apply to each process area, naturally there is

variation in how each generic goal and practice affects the core subject matter of

a process area. For example, generic practice 2.1, which calls for governance over

the process, will differ widely depending on whether the process deals with

incident management or organizational training and awareness. Thus, in each

process area, the CERT-RMM model includes customized examples of the generic

goals and practices. These customized examples are called elaborations, and

therefore each process area has a unique set of elaborated generic goals and prac-

tices associated with it.

Elaborated generic goals and practices are included with each process area,

beginning in Part Three of this book.

5.5 Applying Generic Practices

Applying the generic practices in CERT-RMM is mostly straightforward but can

be confusing. It is easiest to start with a simple example.

When you are achieving the specific goals of the Asset Definition and

Management process area, you are formally identifying, documenting, and

managing the assets that the organization depends on to ensure that high-value

services meet their missions. Consider generic practice GG2.GP2, “Establish

and maintain the plan for performing the process.” In this context, generic

practice GG2.GP2 reminds you that you need to plan the activities related to

identifying, documenting, and managing assets throughout their life cycle.

Thus, the application of this generic practice improves the institutionalization

of the Asset Definition and Management process area by instilling a planning

discipline.

In some cases, the application of a generic practice to the specific goals in a

process area will seem recursive. For example, consider the application of generic

practice GG2.GP2 to a process area that already includes a specific goal directed

at planning. In the Incident Management and Control process area, planning for

incident management is a major aspect of the process. The application of generic

practice GG2.GP2 in this case reminds you that you must plan the activities

involved in creating the plan for managing incidents.

5.6 Process Areas That Support Generic Practices

While generic goals and generic practices are the model components that directly

address process institutionalization, some process areas also address institution-

alization by supporting the implementation of the generic practices. Thus, imple-

menting the specific practices in some process areas may also help with the

implementation of a generic practice.

Chapter 5 Institutionalizing Operational Resilience Management Processes 75

Table 5.3 shows the relationship between CERT-RMM process areas and

generic practices.

TA BL E 5 . 3 C ERT- R MM Ge n e ri c Pra c t ice s Su p p or t e d by Pro ce ss A re as

How the Process Area Helps to

Generic Practice Related Process Area Implement the Generic Practice

GG2.GP1 Enterprise Focus Enterprise Focus addresses the

Establish Process governance aspect of managing

Governance operational resilience. Mastery of the

Enterprise Focus process area can help to

achieve GG2.GP1 in other process areas.

GG2.GP3 Human Resource Management Human Resource Management ensures

Provide Resources Financial Resource that resources have the proper skill sets

Management and their performance is consistent over

time. Financial Resource Management

addresses the provision of other resources

to the process, such as financial capital.

GG2.GP5 Organizational Training Organizational Training and Awareness

Train People and Awareness ensures that resources are properly

trained.

GG2.GP8 Monitoring Monitoring provides the structure and

Monitor and Control Measurement and Analysis process for identifying and collecting

the Process relevant information for controlling

processes. Measurement and Analysis

provides general guidance about

measuring, analyzing, and recording

information that can be used in

establishing measures for monitoring

actual performance of the process

[CMMI Product Team 2006].

GG2.GP10 Enterprise Focus As part of the governance process,

Review Status with Enterprise Focus requires oversight of the

Higher-Level Managers resilience process, including identifying

corrective actions.

GG3.GP1 Organizational Process Organizational Process Definition

Establish a Defined Definition establishes the organizational process

Process assets necessary to implement the generic

practice [CMMI Product Team 2006].

GG3.GP2 Organizational Process Organizational Process Definition

Collect Improvement Definition establishes the organizational process

Information Organizational Process Focus assets. Organizational Process Focus

addresses the incorporation of

experiences into the organizational

process assets [CMMI Product Team 2006].

This page intentionally left blank
